Centrifugal sump pumps – SERIES CGV-L
The vertical centrifugal with coupling range CGV-L, has been designed in order to obtain the best performances and a total reliability. Easy to handle, the pumps of this range are strong, compact construction, produced in their components with high thickness to give a product with the maximum strength.
Material of Construction
Suitable to transfer acid and basic solutions, the wet ends, are produced in thermoplastics (PP-PVDF) and O-ring in the proper elastomer material (EPDM-FPM-FEP-FFKM). Pump shaft connected to the motor through the elastic coupling with inside ball bearings, is guided through PTFE CG and Al2O3 (alumina) bushings; available upon request is the alternative combination in SiC-SiC (silicium carbide).
Accessories
• Flanged connection on discharge line
• Motor rain guard
• Filter on suction line
• Extension pipe on suction line
