Horizontal centrifugal pumps with mechanical seal – SERIES CDM ISO 2858 / EN 22858

The centrifugal monobloc series CDM CDM-E, have been designed in order to obtain the best performances with a reduced cost. Easy to handle, the pumps of these series are strong, produced in their components with high thickness to give a product with the maximum reliability. Primary label mechanical seals combinations are installed (internal, external and double flushed). Example of application: Sulphuric Acid (H2SO4), Hydrochloric acid (HCl), Sodium Hypochlorite (NaOCl), Nitric acid (HNO3), Caustic Soda (NaOH), Phosphoric acid (H3PO4), Ferric Chloride (ZnCl2), etc.

Material of Construction
Suitable to transfer acid and basics solutions, the parts in contact with the liquid are build from a solid plastic (PP, PVDF, PE-UHMW) block and the gaskets present are in the right material (EPDM, FPM, FFKM).

Accessories
• Draining hole
• Residual fluid collection tank
• Pressurised tank for mechanical flushing
